DeWulf Kwatro Harvester – Technical Specification
General Features
• Type: Self-propelled 4-row potato harvester
• Automatic levelling with manual operation via control pedals
• Machine Load Monitoring: Pressure sensors on sieving conveyors and hedgehog unit, displayed in the control unit
Engine & Drive
• Engine: Scania DC13, 368 kW (500 hp), Stage V compliant
• EcoDrive: Automatic rpm adjustment for efficient harvesting
• Hydrostatic drive: 0–25 km/h
• Road rpm: 1600; Field max rpm: 1900
• Exhaust: Venturi system
Rear Axle
• Steerable central rear wheel: 64° left, 56° right, position indication and automatic neutral
• Traction: Adjustable per wheel, automatic gear option
• Tyres: Mitas 1250/50 R32, max 1.4 kg/cm²
Haulm Chopper
• Type: 4-row haulm topper, pulverizes haulm and deposits between ridges
• Material: Durable hood
• Rotor: For 750 mm row distance
• Automatic Depth Control (ADC): With skid plate
Harvesting Unit
• Frontal harvesting unit: Support rollers, single harvesting shares (adjustable inclination), haulm intake rollers
• APC: Automatic pressure control, adjustable weight relief per 1 bar
• Spray Track Detection: Maintains fixed position during rapid skid movement
• Shares: 475 mm wide, break bolt system
• Support wheels: 5 steel wheels, 100 mm wide middle support wheel
• Automatic Steering (DAS): Monitors ridge, steers back wheel
Sieving Conveyors
• Conveyor 1: 2 webs, 1460 mm wide, pitch 50, hydraulically driven, speed/turning adjustable, Syncro Flow
• Conveyor 2: 2 webs, 1460 mm wide, pitch 40, hydraulically driven, Syncro Flow
• Conveyor 3: 2 webs, 1460 mm wide, pitch 40, star PVC, overlap, Syncro Flow
Agitators & Haulm Rollers
• Star agitators: On/off, speed adjustable from cabin
• Haulm roller unit: Spiral roller, cleaning roller, speed/position adjustable from cabin, anti-blocking system
Hedgehog Unit
• Width: 2700 mm (2 x 1350 mm)
• Drive: Hydraulic, divisible universal drive sprockets (ø 180
