Vogesenblitz AMR VPF 22 Holzspalter

Log splitter – available now! Standard features: • Simple and smooth two-hand safety control • Adjustable handles • Two splitting speeds • Rapid piston return • Cylinder stroke 1,050 mm, can be lowered without tools
• Mechanical log lift • Solid steel base plate with slanted edges • Ergonomically shaped splitting wedge • Brass guide • Three-point attachment Cat. I and II • Double pump on all models with electric

Log splitter – available now! Standard features: • Simple and smooth two-hand safety control • Adjustable handles • Two splitting speeds • Rapid piston return • Cylinder stroke 1,050 mm, can be lowered without tools • Mechanical log lift • Solid steel base plate with slanted edges • Ergonomically shaped splitting wedge • Brass guide • Three-point attachment Cat. I and II • Double pump on all models with electric motor • Cast iron pump, robust and powerful (with PTO drive) • Holder for hand saw • Operating instructions VPF 22 Drive: PTO drive Splitting force: 22 t Opening width: 1,150 mm Ram advance (cm/s): Level 1: 11.4 Level 2: 23.3 Ram return: 17.1 cm/s Pump capacity: 69 l/min Cylinder diameter: 110 x 70 mm Hydraulic oil capacity: 62 l Splitting blade length: 285 mm Weight: 545 kg without PTO shaft
