Trak-Met Industriebandsäge TRAK-MET TTS-800/60, 18,5 kW

Powerful industrial bandsaw TRAK-MET TTS-800/60 - efficiency, precision and economy for your sawmill

The TRAK-MET TTS-800/60 has been specially developed for industrial use in sawmills that process up to 30 m³ of logs per 8-hour shift. The model is designed for high performance and low operating costs - ideal for demanding wood processing companies that value quality and efficiency.

The band saw processes log diameters of up to 900 mm and is characterized by precise cutting and high quality of the sawn timber produced. The manoeuvrability of logs weighing up to 4 tons is ensured by sophisticated hydraulic support. A special feature is the cutting band with a width of 60 mm, which enables a cutting quality at the level of wide band saws - but with significantly lower operating and maintenance costs.

✅Main technical features:✅
Weight: 3,400-4,500 kg (depending on equipment)
Main engine power: 18.5 kW (optional 22-30 kW)
Total power requirement (fully equipped): 26-37 kW
Supply voltage: 400 V
Vertical feed of the up/down chain: 30 mm/s
Longitudinal feed of the cutting head: double-sided chain, inverter control 0-30 m/min
Saw blade with stellite cutting edge - 5600x 60x 1.1 tooth pitch 25 mm (efficiency 20-25 m3/10h)
Electric sliding feed for stabilization during the cut
Diameter of the saw guide wheels: 800/43 mm
Standard rail length: 6 m (for log lengths up to 4.8 m)
Cutting width: 1.5-2.2 mm
Cutting head distance: 420-900 mm
MICRON-PRO saw measuring sensor for precise cut monitoring
Coolant metering via emulsion solenoid valve
Hydraulic equipment (standard, built-in stationary control panel):
Clamp x 1,
angle
