Güttler GM Striegel 600

No. 72799S
GreenMaster Striegel 600 Overseeding Machine
- with a working width of 6.00 m
- Transport width: 3.00 m
- Hydraulic folding system with dual cylinders and pressure compensation
- Three-point hitch and seeding unit mounting
- Tank frame for mounting a pneumatic spreader with electric or hydraulic blower drive
- with support legs for parking in both the folded and unfolded positions
- with mechanically adjustable harrow intensity (2-bar)
- with tine loss protection
- with 8 rear depth control wheels (height-adjustable)
- With standard coupling kit including a hydraulic coupling plate for attaching the trailing roller
- With warning signs featuring LED lighting
Optional equipment:
- With a foldable Ripperboard 600 QUATTRO

- with EPS 5 pneumatic spreader, 410 L, rotated 90°, hydraulic, with reinforced hydraulic blower
consisting of:
Reinforced hydraulic blower BV with pressure gauge
Discharge opening with slide gate
1 m hose, Ø 60 mm, including clamp
Reinforced gearbox
3 m hydraulic hose set
90 cm hose, Ø 76 mm (blower – seeder), with 2 clamps
Blower mount
8 double distribution discs
Adjustment plate with screw
2 metering rollers (8R3S and 8R1SD)
GÜTTLER calibration bag
Seed hose, Ø 26 mm, coated
Seed scale

- with SeedProfi Basic Version control electronics
consisting of:
Terminal with 5-inch color display
Magnetic base mount
Electronically controlled seeder drive with daily and total area counting
Manual pre-metering
5 m data connection cable between terminal and control box
Standard SG1 electric motor
Calibration and hopper emptying buttons on the control box; electronic hopper level monitoring
Sensor in the hopper for empty signal
7-pin cable for the speed signal
The Schwarzmayr sales team would be happy to show you the equipment or
